APCP-1700 Series
APCP-1700 Series
Automatic Pool Cover Pump
Little Giant Pool Cover Pumps help safeguard and protect the pool cover from prolonged accumulation of rain or melting snow. We offer manual and automatic versions of pumps certified for use on pool covers, all of which can attach to a standard garden hose for easy water removal.
-
Application
- Automatic pool cover pump designed specifically for pool cover draining
Features
- Removable intake screen for easy cleaning and maintenance
- Built-in handle for portability and ease of placement and removal
- Integrated float switch for reliable automatic operation
- Side discharge for optimal water removal
- Weighted to attract water to the pump
Specification
- Head: up to 6.5 m / Flow: up to 108 l/min
- Min. head: 0.3 m at 108 l/min flow ( 1 ft at 1700 GPH flow)
- Higher flow for head heights of 0,3 m compared to similar pumps
- P1: 270 W / P2: 0,25 kW (1/3 HP)
- Voltage: 230 V / Frequency: 50 Hz / In: 1.2 A
- Temperature range of pumped liquid: 0 °C - 35 °C (EN60335-2-41)
- Ambient temperature: max 35 °C
- Start/Stop Automatic: Start 6.3 cm (2" 1/2) / Stop: 2.5 cm (1")
- Protecion degree: IP68
- 10 m cable with Schuko plug
- 3/4" garden hose connection
Sales info
- Item number: 577303
- CE Certification
-
Hydraulic performance at 230 V - 50 Hz
Q = DELIVERY l/min 0 8.3 17 25 33 42 50 58 67 75 83 l/h 0 498 1020 1500 1980 2520 3000 3480 4020 4500 4980 US GPM 0 2.2 4.5 6.6 8.7 11 13.2 15.3 17.7 19.8 22 H = TOTAL HEAD METRES COLUMN OF WATER [m] 6.5 6.2 5.7 5.2 4.7 4.2 3.7 3.2 2.7 2.2 1.8 -
