Applications

• For clean and dirty water, containing solids up to 35 mm grain size
• The construction with smooth surfaces in rolled-stainless steel and easy access for cleaning is suitable for certain uses in the food industry

FOR CLEAN AND DIRTY WATER, SOLIDS UP TO 35 MM

• Containing solids up to 35 mm grain size
• Stainless steel pump casing and impeller
• Vertical delivery port
• Double mechanical seal in oil chamber
• Dry winding motor, designed in accordance with: EN 60034-1; EN 60335-1, EN 60335-2-41

General features

Model		ED
Max. head [m]:		13
Flow [m3/h]:		up to 26 m3/h
Liquid temperature range [°C]:		up to 35 °C
Minimum immersion depth [mm]:		248 mm
Maximum immersion depth [m]:		5 m
Maximum solids size [mm]:		35 mm
Power cable:	Single Phase	H07RN-F, 3G1 mm2, length 10 m (5 m for ED5), with plug Cel-UneL 47166 / Schuko
Motor power [kW]:		0.55 - 0.9 kW
Motor type:		2-pole induction motor, 50Hz (n ≈ 2900 rpm)
Motor standard voltage:	Single Phase	230 V ± 10 %; with float switch and thermal protector
Protections:		Insulation class F Protection IPX8 (for continuous immersion) Triple impregnation humidity-proof dry winding
Capacitor:		Built-in for single phase version
Float switch:		Included in single phase version
